Nylon Flexible Pipe Tube Holder

Catalog Download

Technical Parameters

Product material
PA (Polyamide)
Working temperature
-40℃~+110℃
Features
1. Two types available for selection:with lid and without lid Property:
2. Use for plastic corrugated conduits. It's used for fixing and stable conduits or cables.
Color
Black & light gray color in standard .Other colors can be customized .
Protection level
Low smoke zero halogens.
Property
PJ bracket provide firm support for conduit,used for securing the flexible conduits or cables,etc.
Nylon Flexible Pipe Tube Holder
Nylon Flexible Pipe Tube Holder

Decomposition Diagrams

Technical Data sheet

Nylon Conduit Holder
Cat. No. Adaptive Pipe A
(mm)		 B
(mm)		 T
(mm)		 H
(mm)		 M
(mm)		 Std.pkg
(pcs/bag)
Inch Size
PJ-VH-10.0 1/4'' AD10.0 6.5 25 12.5 26 4 100
PJ-VH-13.0 5/16'' AD13.0 6.5 30 12.5 26 4 100
PJ-VH-15.8 3/8'' AD15.8 6.5 30 12.5 26 4 100
PJ-VH-18.5 　 AD18.5 6.5 35 15 33 5 100
PJ-VH-21.2 1/2'' AD21.2 6.5 35 15 34 6 100
PJ-VH-25.0   AD25.0 11.5 42 16 38 6 50
PJ-VH-28.5 3/4'' AD28.5 11.5 42 16 42 6 50
PJ-VH-34.5 1'' AD34.5 11.5 51 16 49 6 50
PJ-VH-42.5 1 1/4'' AD42.5 11.5 58 18 57 6 50
PJ-VH-54.5 2'' AD54.5 12 73 20 70 7 50
